Easy to use, point-to-point positioning

Digitax Indexer

Control Techniques

Control Techniques' AC drives provide world-class solutions to a wide range of applications and industries. AC drives also known as variable frequency drives (VFD), variable speed drives (VSD), adjustable-speed drives or inverter drives also referred to as motor controls.

Control Techniques drives offer:

  • Wide power and voltage ranges with advanced motor control

  • Extendable through a large range of option modules

  • Compact with onboard programming and motion control

  • Robust design for long and reliable service

Digitax Indexer

a standalone controller or integrate with a wider automation system using fieldbus and I/O.

Easy to use, point-to-point positioning

available models:

  • DST120X single phase

  • DST120X three phase

  • DST140X three phase


Quote request

Quote request Digitax Indexer

Request more information

Request more information about Digitax Indexer

Download datasheet
Details / Specifications / Documents

Details

  • DST120X single phase

  • DST120X three phase

  • DST140X three phase

Easy to use, point-to-point positioning


Enhance machine performance through easy integration with any motion controller

  • Integrated high resolution analog input and encoder output
  • Predefined digital I/O for controller connection
  • Integrated high speed freeze input
  • Digital servo networks (EtherCAT, SERCOS and CANopen) available via option module

Tailor the drive to a variety of application requirements

  • On-board encoder input supports Incremental, SinCos, Hiperface, EnDAT and SSI encoders
  • Two option slots for functionality expansion via a full range of option modules

Simplified motion programming

  • Configure positioning applications quickly and easily using powerful graphical software
  • Access advanced features such as drive-to-drive communications through positioning applications developed specifically for the Indexer
  • Tailor the drive to a variety of application requirements using options
    • Integrate with wider automation systems with option modules for Ethernet and fieldbus connectivity

  • Reduced downtime with machine safety




Specifications

Level
box
Supplier
Nidec Control Techniques

Documents

We collected the following documentation as PDF-File, that you can access by clicking on the icons.

If you have searched for info  but is not listed, or not completely answering your requirements, perhaps the document you are looking for is not public.

In that case, please contact us by using the following means:

Most of our products can be customized, please contact us Contact
